The SM series is a tried and tested range of compact screw compressors that are built to last. The robust compressor cabinet design features cooling air filter mats to prevent premature clogging of the fluid/air cooler and two stage air intake filter by effective filtration of contaminated ambient air that is drawn into and through the cabinet for compression and cooling. Durable, high quality, logically laid out components make these units outstandingly reliable. Combined with optimised component accessibility and removable panels for ease of maintenance, the advantages are obvious.

Model : SM12 (RM) Sigma Basic Controls
Performance (F.A.D) * : 1.01m³/min (35.66cfm) @ 10 bar
Motor Size : 7.5kW
Motor Spec. : IP54 Class 'F' Insulation
Electrical Supply : 400v/3ph/50Hz
Noise Level** : 64dB(A)
Air Outlet Connection : ¾
Overall Length : 630mm / (1310mm)
Overall Width : 762mm / (870mm)
Overall Height : 1100mm / (1735mm)
Net Weight : 210kg / (290kg)
