Condensate is an unavoidable result of air compression. If not reliably drained off at all collection points, it can
cause costly downtime and damage to the compressed air system through corrosion. Electronic ECO-DRAIN
level-sensing condensate drains from KAESER KOMPRESSOREN are therefore the perfect choice to perform
this important task.

Loss-free condensate drainage
ECO-DRAIN condensate drains ensure safe, dependable
condensate drainage without air loss, even
under conditions with widely fluctuating accumulation
and high particle / oil content.

Essential system component
High quality, reliable condensate drains are an essential
component of any compressed air system that
uses premium quality compressors and treatment
equipment. They should also be simple to integrate
throughout the entire system so that compressor
controllers (SIGMA CONTROL 2) and master control
systems (SIGMA AIR MANAGER 4.0) can react
instantaneously to their signals, thereby enhancing
system reliability and performance.

The industry standard
Quality, dependability and safe operation are
essential features of any industrial machinery or
equipment. The ECO-DRAIN meets all of these
requirements. Versions are available to suit even the
most hostile operating conditions, for example: highly
aggressive condensate, freezing temperatures, high
pressure or vacuum. No matter what the application,
KAESER KOMPRESSOREN has the right ECODRAIN
to suit any need.

ECO-DRAIN 30

Pressure Min/Max 0.8/16 bar
Climate Zone 1,2,3
(Climate zone: 1 = Dry/cool (Northern Europe, Canada, Northern USA, Central Asia); 2 = Temperate (Central and Southern Europe, some parts of South America, North Africa),
3 = Humid (South-East Asian coastal regions, Central America, Oceania, Amazon and Congo regions)
Max Compressor Power according to climate zone 1/2/3 (m3/min) 3/2.5/1.5
Dry Power Max 1/2/3 (M3/min) 6/5/3
Filter Performance Max 1/2/3 (m3/min) 30/25/15
Dimensions 164 x 65 x 118mm
