ABAC PRO B4900 200 FT4

This two stage belt drive compressor is a 4 HP static compressor mounted on a 200 litre receiver, suitable for a workshop where three phase is available. It is capable of running standard spray gun, tyre inflator, impact/ratchet wrenches or a low consumption shot blast cabinet. This compressor is the perfect choice for small workshops.

Weight 137 kg
Dimensions 150 × 45 × 96 cm
Range: ABAC PRO
Lubrication : Oil Lubricated
Drive: Belt Driven
Availability: Usually ex stock UK on 2-3 day delivery
Configuration: Stationary
Volt/Hz: 400/3/50
Capacity Displacement CFM: 18
C D CFM Band: Oct-20
Capacity Displacement Litre Per Minute: 514
Capacity Free Air Delivery CFM: 13.8
Capacity Free Air Delivery Litre Per Minute: 390
Maximum Working Pressure PSI: 160
Maximum Working Pressure Bar: 11
Motor HP: 4
Motor kW: 3
Receiver Size in Litres: 200
Noise DB(A) LPA: 78
Noise Power Level LWA: 98
Noise Pressure Level LPA (4 MT) DB(A): 78
Outlet Connection: 1/2" BSP Female
Warranty: 12 months on site warranty
Pump Speed in RPM: 1400
Belt Guard: Plastic
Pump: B4900
Number of Cylinders: 2
Number of Stages: 2
Start Method: DOL
